FRANCE - FRANÇAISISO 4210 Certification
| No. | Test Requirement | Test Item ISO 4210-Part2 MTB |
Test Method ISO 4210-Part6 MTB |
Result |
|---|---|---|---|---|
| 1 | Sec. 4.8.5 | Fatigue Test with Horizontal Forces | Forward：1,200N Downward：600N Time：50,000 Cycles Frequency：3Hz |
Pass |
| 2 | Sec. 4.8.6 | Fatigue Test with a Vertical Forces | Load：1,200N Time：50,000 Cycles Frequency：3Hz |
Pass |
| 3 | Sec. 4.8.2 | Frame and Front Fork Assembly-Impact Test (Falling Mass) | Load：22.5kg Drop Height：360mm |
Pass |
| 4 | Sec. 4.8.3 | Frame and Front Fork Assembly-Impact Test (Falling Frame) | Seat-post：30kg Steering head：10kg Bottom bracket：50kg Drop Height：300mm Drop twice |
Pass |
| 5 | Sec. 4.8.4 | Fatigue Test with Pedaling Forces | Load：1,200N Time：100,000 Cycles Frequency：3Hz |
Pass |
